200mA Driver For Laser Diodes, ILX Model LDX-3412

ILX Model LDX-3412 Driver

The LDX-3412 is a low-cost, precision laser diode driver designed for current controlling general purpose laser diodes. It offers versatile control with constant current and constant power modes, and features a stable, low-noise current performance. The driver also includes ILX Lightwave's unique laser diode protection circuits to safeguard lasers.
______________________________________________________________

Specifications and Key Features
- Output range: 0-200 mA
- Operation modes: constant current, constant power, limit display
- Voltage output: up to 6V
- Laser diode protection: included
- Current limit control: fully independent, precision
- Photodiode feedback capability: user-adjustable
- Display: LED display for easy operation
- Size: 2U half-rack width, 3.5 inches high
- Weight: 2.5 lbs
- Power requirements: 100-240 VAC, 50/60 Hz, 30 W max.
