PICOSECOND PULSED SEED LASER DIODE DRIVER

Request Quote
sku / item#: 766A
ships: Request a Quote

Key Features
  • Adjustable Pulse Width <150 ps TO >850 ps
  • Output Current up to 2.5 A
  • Compliance Voltage up to 10.0 V
  • Repetition Rate up to 1 MHz
  • On-Board TEC Controller
Product Warranty
All products purchased from Laser Lab Source
are sold with a full one-year warranty.
See terms & conditions for full details.
The Laser Lab Source group websites include:
  • LaserDiodeSource.com
  • LaserLabSource.com
  • LaserDiodeControl.com

Price and Delivery Quote

Technical Questions for this Product

ASK AN ENGINEER

Customers Also Considered:

Why do Scientists & Engineers Choose Laser Lab Source?

MODEL 766A
PRICE Request Price

Product Overview:

AMI’s Model 766A picosecond pulsed seed laser diode driver is ideal for driving 14-pin butterfly packaged laser diode modules for applications which require pulse widths less than 1 ns. Applications include materials processing, time-resolved spectroscopy, LiDAR and others. The driver circuitry operates from a single 5 V power source. All other needed voltages are generated on the board by high efficiency switching power supplies. The pulse width and amplitude can be adjusted by the on-board potentiometers or external voltage signals. The driver includes a low-noise, bidirectional proportional-integral-derivative (PID) thermoelectric cooler controller (TEC) with current capability of 2.2 A and voltage capability of 4.0 V.
