OEM DUAL CHANNEL CW & PULSED LASER DIODE DRIVER

Request Quote
sku / item#: 788
ships: Request a Quote

Key Features
  • Dual channel output up to 17.5 A each
  • Parallel output up to 35 A
  • Compliance voltage up to 75 V
  • High efficiency of 90%
Product Warranty
All products purchased from Laser Lab Source
are sold with a full one-year warranty.
See terms & conditions for full details.
The Laser Lab Source group websites include:
  • LaserDiodeSource.com
  • LaserLabSource.com
  • LaserDiodeControl.com

Price and Delivery Quote

Technical Questions for this Product

ASK AN ENGINEER

Customers Also Considered:

Why do Scientists & Engineers Choose Laser Lab Source?

MODEL 788
PRICE Request Price

Product Overview:

AMI’s Model 788 Dual Channel OEM CW and Pulsed Laser Diode Driver incorporates a boost converter, capacitor bank, and a current regulated buck converter to provide a programmable current to a laser emitter diode load. Various protections are built in including 48 V soft start, voltage monitoring, temperature monitoring and hysteretic shut down, 48 V and 5 V brown-out protection, start/restart delay, bank dump, current monitoring, and a shorted load until actively released. The PCB is mounted on an aluminum plate that acts to spread and sink heat. Because of the exceptionally high efficiency, cooling arrangements required are minimal. The output current capability is up to 35 Amps pulsed at various duty cycles. Load compliance is up to 75 Volts. Higher CW output currents are possible under certain operating conditions.
