Home  >    >  OsTech   >   sen-613



10kΩ Precision NTC Thermistor,
–40°C to +150°C, Insulated Alloy Leads

  • Precision NTC thermistor 10k ohm

Request Quote
sku / item#: sen-613
ships: 14 to 18 days

Key Features
  • Operating Temperature: –40°C to +125°C
  • Precision NTC Thermistor in an Epoxy Head, Insulated Alloy Leads
Product Warranty
All products purchased from Laser Lab Source
are sold with a full one-year warranty.
See terms & conditions for full details.
The Laser Lab Source group websites include:
  • LaserDiodeSource.com
  • LaserLabSource.com
  • LaserDiodeControl.com
Shipping Information

Price and Delivery Quote

Technical Questions for this Product

ASK AN ENGINEER

Customers Also Considered:

Why do Scientists & Engineers Choose Laser Lab Source?

MODEL sen-613
PRICE Request Price
General Specifications
  • Operating Temperature: –40°C to +125°C
  • Rated Temperature: +25ºC
  • Resistance Tolerance: ±0.5%
  • Thermal Conductivity (Air): approx 0.75 mK/W
  • Beta Value: at 25/85ºC
  • Lead Wires: Alloy AWG 32, Insulated Leads
  • Diameter: 2.41 mm
Thermistor Constants for
OsTech Temperature Controllers
  • xTSC0-273.15
  • xTSC11.1290e-3
  • xTSC22.3416e-4
  • xTSC38.7553e-8
  • xTSM1

Product Overview:

Sealed Epoxy Head Precision NTC Thermistor

This NTC thermistor is molded into an epoxy head, and features alloy lead wires for reduced thermal conductivity. The lead wires are insulated.
