3 Amp Pulse Driver For Laser Diodes, PicoLAS Model LDP-V 03-100 V3.3

LDP-V 03-100 V3.3 Pulse Driver

The LDP-V 03-100 V3.3 is a compact OEM module designed for driving pulsed laser diodes. It offers pulse width control, current monitoring, and a range of other features, making it ideal for applications such as LIDAR, rangefinding, and biochemistry. The device is optimized for pulse repetition from single shot up to MHz repetition with duty cycles up to 100%.
______________________________________________________________

Specifications and Key Features
- Compact OEM module
- Diode current range: 0.3 to 3 A
- Rise time: < 1.2 ns
- Pulse width control via SMC trigger input (1 ns to >10 μs)
- Repetition rates from single shot to 35 MHz
- Single supply operation
- Current monitor and isolated monitor outputs
- Operating temperature range: -20 to +55 °C
- Dimensions: 75 x 44 x 20 mm
- Weight: 76 g
- Power dissipation: 15 W
- Optional high voltage supply: 0 .. 100 V, 15 W
- Compatible laser diode packages: TO-18, TO-5, TO-52, 5.6 mm, 9 mm, and similar

Please note that these specifications are subject to change, and for more detailed information, it is recommended to refer to the manual.
