6 Amp Driver For Laser Diodes, ILX Model LDX-3565B

ILX Lightwave LDX-3565B Driver

The ILX Lightwave LDX-3565B is a series precision laser diode driver that offers multiple protection features in addition to a high stability output. They are purpose designed current sources with extensive filtering and ESD protection. An easy to use and intuitive front panel interface is complemented by a standard USB rear panel connection, which is offered with LabView drivers. The ILX LDX-3565B is ideal for low to medium power butterfly and TO-can packaged devices and used extensively in R&D Labs around the world.

______________________________________________________________

Specifications and Key Features
- LX Lightwave protection features
- A low noise, high stability DC to 6 Amp output
- USB or front panel control
- Current Range: 0 - 6 Amps
- Compliance Voltage (max): 0 - 5V
- Noise & Ripple (rms): 50 µA (low bandwidth mode)
- Current Setpoint Resolution: 1.0 mA
- Current Setpoint Accuracy: +/- 0.5%
- Output Accuracy: +/- 0.1% of full scale
- Slow-Start Circuitry
- Voltage / Current Limits
- Transient Filters
- Interlock Shut Off
- Transfer Function: 200 mA/V
- Input: 0-10V
- Connector: BNC
- Range: 100kHz (high BW)
- (-)PD Bias Supplied: 0 - 5V
- Measurement Range: 0 - 25000µA
- Front Panel, 4 Digit LED
- USB
