Laser Diode Heat Sink, ILX Model LDM-4442

ILX Lightwave model: LDM-4442
The ILX Lightwave model LDM-4442 is a laser diode heat sink designed for high power devices. It provides secure positioning for several package styles, including the HHL and the TO-3 style package. These mounts provide a method for locating these lasers above an optical table or rail with a standard mounting pattern. They are intended for laser packages that dissipate over 5 watts of laser power. The heat sink can be configured with water cooling for the efficient removal of up to 50 watts of thermal power. Applications which require unobstructed access to the front of the laser package are well suited for these models. These units consists of a base stand, a water-cooled riser, and a heat sink with a cable strain-relief clamp. An assortment of laser mounting plates can be ordered as options to provide easy attachment of different laser packages. With or without the detachable base stand, they can be attached directly to optical tables having the standard 1/4-20 on 1" centers, hole pattern. When used with the base stand, the mount locates the laser package at a nominal height of 4.0".

Specifications and Key Features:
- These heat sinks offer an integrated water cooled base plate to efficiently remove heat and prevents thermal damage to your laser diode.
- Package Styles: HHL and TO-3
- Temperature Control Range: 10 to 80 °C
- Heat Dissipation: 50W
- Maximum Current Load: 7 Amps
- Collimating Lens Options: Not Available
- Thermal Resistance: 1.4 Degrees C/W
