C-Mount Temperature Controlled Fixture, ILX Model LDM-4409

ILX Lightwave model: LDM-4409
The ILX Lightwave LDM-4409 C-mount laser diode fixture and cooling module is a high performance mounting and control solution for C-mount header devices. A high power integrated TEC module provides a wide temperature control range and quickly removes heat from the device under test to prevent thermal damage. The easy to use 4409 series C-mount fixture from ILX Lightwave provides safe and reliable mechanical control of your laser. An integrated clamping lever provides excellent thermal contact from the C-mount to the cooling base plate, and internal TEC modules maintain highly stable temperature.

Specifications and Key Features:
- Package Styles: C-Mount
- Temperature Control Range: 10 to 80 °C
- Power: 7.4 A, 16.4V
- Connectors: Female Hybrid DSUB 7W2 (Diode), Male Hybrid DSUB 7W2 (TEC), Female Bananna Jacks (Fan Power and Ground)
- Integrated TE Sensor: 10 kΩ NTC thermistor
