4 Amp Laser Diode Controller, ILX Model LDC-3744C

ILX Lightwave model LDC-3744C

The LDC-37X4C series from ILX Lightwave is a high stability precision laser diode current source and temperature controller. Multiple layers of laser diode protection ensure that your device is protected at all times, while the ultra-stable temperature controller provides fast and efficient heat removal from the laser diode under test.
An easy to use and intuitive front panel interface is complemented by standard GPIB and USB rear panel connections which are offered with LabView drivers. The 3700C is offered with your choice of 500mA or 4 Amp outputs and is used extensively in R&D Labs and manufacturing environments around the world.

Specifications and Key Features:
- Output Current Range: 0 - 4A
- Compliance Voltage (max): 10V
- Current Setpoint Resolution: < 10 uA
- Current Setpoint Accuracy: +/- 0.05 % of full range
- Current Stability (24 hour): < 40 ppm / °C
- Current Limit Range: 0 - full scale
- Voltage Measurement Accuracy: +/- 2.5%
- TEC Output Current: -4 Amps to +4 Amps
- TEC Output Voltage (max): 8V
- Maximum TEC Output Power: 32W
- Temperature Setpoint Resolution: 0.1 °C
- Temperature Stability (typical - 1 hr): < 0.004 °C
- Temperature Control Range: -100 °C to +199 °C
- TEC Power Output Type: Bipolar
- Compatible Temperature Sensor: Thermistor and IC sensors
- TEC Current Limit Range: 0 to 4 Amps
- PD Measurement Range: 5 to 5000 uA
- PD Setpoint Accuracy: +/- 0.05 %
- PD Reverse Bias Control: 0 to -5V User Settable
- Bandwidth (3 dB): DC to 250kHz
- Input Range: 0 to 10V
- Input Impedance: 10 K ohm
