High Power Laser Diode TEC Controller, 255W

$429.00   Ships: Stock | Model PTC10K-CH

Key Features
  • Output Current: ±10 A
  • Temperature Stability (1hr): 0.0012°C (@ 25°C)
  • Small package: 3.0 x 3.2 x 1.1 inches
  • Remote Output and Setpoint controls
  • Selectable Sensor Bias Current
  • Adjustable Current Limit
  • PI control with

Price and Delivery Quote

You will receive factory-direct price with no mark-ups

Technical Questions for this Product

ASK AN ENGINEER

Questions route directly to the correct Product Engineer

Why do Scientists & Engineers Choose Laser Lab Source?

  • NO SALES PERSON. Get direct access to the correct product ENGINEER. learn more »

  • NO MARK-UP's. Manufacturer's set their own lowest direct pricing. learn more »

  • LEADING BRANDS. We make it simple to buy from top Global suppliers. learn more »

Customers Also Considered:

MODEL PTC10K-CH
PRICE $429.00
General SPECIFICATIONS
  • Output Current: ±10 A
  • Input Supply Voltage: 4.5 VDC to 30 VDC
  • Temperature Stability (1hr): 0.0012°C (@ 25°C)
  • Operating Temperature: -40 to 85 ºC
  • Storage Temperature: -65 to 125 ºC
  • Weight: 4.3 oz
  • Size: 1.3 x 1.28 x 0.313 inches

Product Overview:

The PTC10K-CH Series Chassis Mount Temperature Controllers deliver the precision performance and long-term reliability you expect from a Wavelength Electronics temperature controller. These controllers are found in diverse applications as particle and droplet measurement, manufacturing machine vision systems, biomolecular interaction analysis, and more.

The PTCxK-CH Series are high-current linear temperature controllers that deliver bidirectional current to Peltier Effect thermoelectric coolers, or unidirectional current to resistive heaters.

The controller operates from a single power supply between 5 V and 30 V. The linear bipolar controller drives a Peltier thermoelectric cooler or a resistive heater, and integrates easily into OEM applications. It has features that help protect the load from damage and also make it more versatile in a wide array. The controller employs a smart ProportionalIntegrating control loop to adjust the drive current. It can be configured to use a remote signal to enable the output, or it can be configured so that the output is always on whenever power is applied to the unit.

The PTCxK-CH controllers interface with a variety of temperature sensors, and the bias current is adjustable in order to maximize controller sensitivity and stability. The compact chassis mount design simplifies heatsinking and requires minimal space.

The PTCxK-CH controllers are easy to configure for your prototype project, and there are no surprises when it’s time to integrate the controller into final design.
