6 Watt TEC Controller, ILX Model LDT-5412

TEC Controller LDT-5412

The LDT-5412 from ILX Lightwave is a bipolar TEC controller designed to have the features you need at a price you can afford. This economical laser diode temperature controller offers several thermistor current sense supply settings and displays resistance units of the laser's thermistor. The control loop is a hybrid PI loop designed to deliver fast settling times with a typical long term temperature stability of +0.01C.


______________________________________________________________

Specifications and Key Features
Range: -2.0 to +2.0 Amps
Voltage (max): +/- 3V
Type: Bipolar - Linear
Setpoint Resolution: 0.01 Amps
Stability: +/- 0.005°C (1hr)
Control Algorithm: Proportional Adjustable, Integral Fixed
Limit: Front Panel Set, Resistance Units

SENSOR
Thermistor NTC (2 wire)
Thermistor Sensor Resistance: 0 to 199.9K Range
Thermistor Sensor Resistance: 0.1K Resolution

INTERFACE
Front Panel: 4 segment LED
Rear Panel: 15 Pin D-Sub Connector
